LUOWAVE LW-B210
$2,140.00
?CE Certified?LUOWAVE LW-B210 Dual-Channel MIMO SDR Platform | Spartan-6 FPGA & AD9361 2T2R | USB 3.0 | Compatible with USRP B210 Ecosystem
⚠ Only 7 left in stock
SKU: LLW-B210
Category: Physical Products
LUOWAVE LW-B210 | 2 TX/RX Channels, AD9361 RF 70MHz-6GHz, 56 MHz BW Each, Software Defined Radio Device
The LW-B210 is a highly integrated, dual-channel Software-Defined Radio (SDR) device that supports an RF frequency range of 70 MHz to 6 GHz. It features a high-speed USB 3.0 interface, enabling compatibility with various SDR frameworks. The device utilizes programmable optional Xilinx Spartan-6?Artix™ 7 200T/100T FPGA, and an AD9361 RF front-end to provide a maximum real-time bandwidth of 56 MHz.
Specifications
DC Voltage Input 6V GPS Lock TCXO Accuracy <1ppb
ADC Sampling Rate (Max) 61.44 MSps Single-sideband Mirroring
LO Rejection(1GHz) -40/-50dBc
ADC Resolution 12 bits 1GHz Phase Noise -102dBc/Hz@10KHz
ADC Wideband SFDR 78dBc 5GHz Phase Noise -91dBc/Hz@10KHz
DAC Sampling Rate 61.44 MSps Output Power 16dBm
DAC Resolution 12 bits IIP3 -20dBm
Maximum Tansfer Rate With Host (16b) 61.44 MSps Noise Figure <8.5dB
Local Oscillator Accuracy ±2.0ppm Unlock GPS TCXO Accuracy ±75ppb
Processor(only for Chassis) I7 8700 Memory(only for Chassis) 16G
Voltage(only for Chassis) 220V Current(only for Chassis) 3A MAX
Size Spartan6: 0.695kg
A7 200T: 0.8kg
A7 100T: 0.11kg
Intergrated Chassis: 2.8kg Weight Spartan6: 17.5*10*1.7cm
A7 200T: 17.9*12.7*4.8 cm
A7 100T: 17.2*10 cm
Intergrated Chassis: 23.5*30*8.5 cm
The LW-B210 is a highly integrated, dual-channel Software-Defined Radio (SDR) device that supports an RF frequency range of 70 MHz to 6 GHz. It features a high-speed USB 3.0 interface, enabling compatibility with various SDR frameworks. The device utilizes programmable optional Xilinx Spartan-6?Artix™ 7 200T/100T FPGA, and an AD9361 RF front-end to provide a maximum real-time bandwidth of 56 MHz.
